What is Miscanthus?

 Miscanthus is a tall perennial grass that has been accepted as a good high yield biomass crop for use in Europe during the past 5-10 years. It is sometimes confused with elephant grass (Pennisetum purpureum) and has been called both "elephant grass" and "E-grass". Most of the miscanthus cultivars proposed as a commercial crop in Europe are sterile hybrids (Miscanthus x giganteus) which originated in Japan.

A number of ornamental varieties of miscanthus are also known to exist under various common names. Miscanthus can be harvested every year with a sugar cane harvester and can be grown in a cool climate like that of northern Europe making it ideal for Ireland. Like other bioenergy crops, the harvested stems of miscanthus may be used as fuel for production of heat and electric power, or for conversion to other useful products such as ethanol.

Burning Miscanthus as a Home Heating Fuel

Miscanthus has the potential to supply a major part of the biomass renewable energy sector needs in the future, however, there are some problems related to burning miscanthus in standard wood chip and wood pellet boilers.  The ash produced when burning Miscanthus melts at a much lower temperature than ashes produced when burning wood. As a result if you burn miscanthus in a typical wood chip/pellet boiler it will be treated as if it is wood and burn at much higher temperatures than it should be. These high temperatures cause the ash to melt and then form a hard crust in the burning chamber – otherwise known as clinker.

ETA have overcome this problem by using a unique flue gas recirculation system in their boilers. By recirculating burnt gases to the primary air inlet the amount of oxygen in the burning air is reduced and thereby cools down the burning process. This cooling process prevents the build up of clinker in the fire bed and allows the fire to burn efficiently and without problem.  In addition the ETA boilers have a tilting grate that periodically empties any ash build up in the burning chamber directly into the ash bin.
